Temporary bridges
It is essential to minimize disturbances when carrying out maintenance and repair work on railway networks. Temporary bridges are installed for trains to continue running along their designated tracks when constructing railway bridges without affecting normal operation. Culverts, roads, paths or even entire bridges can be constructed under these temporary bridges. LEONHARD WEISS can supply everything you need from one single source when installing and disassembling temporary bridges.
- Transport of temporary bridges
- Installation using their own front rail hoisting cranes (GS 150.17 TR or KRC 1200UIC)
- Installation from lateral storage using truck cranes
- Installation of temporary bridges in tandem
- Welding on supports
- Upkeep of the temporary bridge during Construction period
- All measuring work on the rail and temporary blip, including documentation
Railway bridge Saalbachkanal Graben-Neudorf
Customer: DB Netz AGConstruction period: 28 months Year of construction: 2022–2024
- Delivery with road logistics and installation of 2 auxiliary bridges ZH 24 (weight up to 60 t each) in June 2022
- Delivery with railway logistics and installation of 3 auxiliary bridges ZH 24 (weight up to 60 t each) in November 2022
- Track dismantling incl. complete excavation before the upgrade of the existing bridge 5 x 50 m
- Track construction incl. complete renovation of track bed over new auxiliary bridges 5 x 50 m
- Construction-temporal dismantling of existing point incl. closing of gap
- Construction-temporal relocation of the existing point incl. reinstallation
Railway flyover Söllingen
Customer: Albtal-Verkehrs-Gesellschaft mbHConstruction period: 20 months Year of construction: 2022–2023
- Delivery and removal of the auxiliary bridge per heavy-load truck HB-ZH24 Length = 24 m Weight = 54 t
- Installation and deinstallation of the auxiliary bridge by means of a railway crane
- Superstructure works for installation and deinstallation of the auxiliary bridge
Railway overbridge Wertach
Customer: DB Netz AGConstruction period: 7 months Year of construction: 2021
- Track dismantling for installation of auxiliary bridges
- Installation of 2 auxiliary bridges ZH07 with a span of 7.20 m
- Delivery and installation of supporting beams and elastomer support
- Work on superstructure after push-in of bridge
- 1,500 m work through tamping
Railway overbridge Ditzingen
Customer: WOLFF & MÜLLER, DB Netz AGConstruction period: 7 months Year of construction: 2021–2022
- Track dismantling for installation of auxiliary bridges
- Installation of 2 auxiliary bridges ZH 26 with a span of 26.40 m
- Delivery and installation of supporting beams, as well as the hydraulic articulated sliding bearings
- New construction of tracks on new bridge 2 x 36 m
- Underground cable engineering 600 m
- Lifting into position by means of mobile crane
Renovation stopping station Stetten-Beinstein
Customer: DB AG StuttgartConstruction period: 12 months Year of construction: 2019 / 2020
- Superstructure works like track dismantling and construction (2 x 25 m)
- soil stabilisation (160 m³)
- installation of 2 auxiliary bridges ZH 9 with shallow foundations (dismantling November 2020)
- tamping works
- welding works (8 pcs.)
- platform edges and renovation of foundations
- conversion areas 2 x 25 m
Renovation railway overbridge Auweg, train station Günzburg
Efficient track construction for new construction of railway overbridge
Customer: Vitus Rieder, BissingenConstruction period: August 2019–December 2020 in various construction phases
- Dismantling and installation of tracks and points in various construction phases for site clearance for the renovation of the railway overbridge “Auweg“
- Installation of 4 auxiliary bridges, each with 9.60 m effective span, weight 15 t
- Renovation of approx. 300 m track
- Dismantling and installation incl. partial renovation of 3 points
- New construction of 40 m platform incl. underground cable engineering and drainage
Renovation Pegnitztal bridges, Velden
Conversion works on 3 railway overbridges: Artelshofen, Steinbruch and Velden
Customer: Implenia Construction GmbHConstruction period: two and a half weeks complete shut down in August 2019 and August 2020
- Traditional stabilisation of formation (1,450 m³)
- Adaptation of gradients in existing track (634 m)
- Production cycle path (30 m)
- Installation percolating half-shells (201 m)
- Renovation of percolating filter (191 m)
- Railway overbridge Artelshofen (2 x 40 m)
- Railway overbridge Steinbruch (2 x 35 m)
- Railway overbridge Velden (2 x 90 m)
Track construction work per railway overbridge
Tunnel Diez
Customer: ARGE Tunnel DiezConstruction period: 2 months Year of construction: 2018 / 2020
- Earth works and track construction works for the customer during the construction phase
- Installation of 4 pcs auxiliary bridges with 12 shutdowns during week-ends:
- 2 pcs ZH24 (span: 24.54 m / total weight: 54,089 t)
- 2 pcs ZH31 (span: 31.74 m / total weight: 107,400 t)
- Lifting in position by means of railway construction cranes
